| Fixed Ethernet Interface |
1 x GE |
1 x GE |
4 x GE (M12 interface) |
4 x GE (M12 interface) |
4 x GE (M12 interface) |
| LTE |
FDD LTE: B1/B2/B3/B4/B5/
B7/B8/20B7/B8/B20
UMTS: B1/B2/B5/B8
GSM/GPRS/EDGE: 850 MHz/900 MHz/1,800 MHz/1,900 MHz |
FDD LTE: B1/B2/B3/B4/B5/
B7/B8/B20 UMTS: B1/B2/B5/B8
GSM/GPRS/EDGE: 850 MHz/
900 MHz/1,800 MHz/
1,900 MHz |
2 x LTE modules supporting 4 SIM cards FDD LTE: B1/B3/B8
TDD LTE: B38/B39/B40/B41
UMTS: B1/B5/B8/B9
TD-SCDMA: B34/B39
GSM/GPRS/EDGE: 1,800 MHz/900 MHz |
4 x LTE modules supporting 8 SIM cards
FDD LTE: B1/B2/B3/B4/B5/B7/B8/
B20
UMTS: B1/B2/B5/B8
GSM/GPRS/EDGE: 850 MHz/900 MHz/1,800 MHz/1,900 MHz |
- |
| Wi-Fi |
Dual-band AP (2.4 GHz and 5 GHz), 2 x 2 MIMO 802.11ac and 802.11b/g/n |
Dual-Band APs including both 2.4 GHz and 5 GHz access;
2 x 2 MIMO 802.11a/b/g/n |
Dual-Band APs including both 2.4 GHz and 5 GHz access;
3 x 3 MIMO 802.11ac and 802.11b/g/n |
Dual-Band APs including both 2.4 GHz and 5 GHz access;
2 x 2 MIMO 802.11ac and 802.11b/g/n |
Dual-Band APs including both 2.4 GHz and 5 GHz access;
3 x 3 MIMO 802.11ac and 802.11b/g/n |
| GPS |
Supported |
Supported |
Supported |
Supported |
- |
| Memory |
1 GB |
1 GB |
1 GB |
1 GB |
1 GB |
| Storage |
Built-in Flash 512 MB
(expand storage through mSATA interface) |
Built-in Flash 512 MB
(expand storage through mSATA interface) |
Built-in Flash 512 MB and mSATA SSD 128 GB |
- |
Built-in Flash 512 MB and mSATA SSD 128 GB |
| PoE |
- |
- |
Supported
GE0 to GE3 support PoE, maximum 20W |
Supported
GE0 to GE3 support PoE and PoE+, maximum 30W |
Supported
GE0 to GE3 support PoE and PoE+, maximum 30W |
| Power Supply |
DC inputs: 8V to 36V |
DC inputs: 8V to 36V |
DC inputs: 9V to 36V
ACC check supported |
100V DC/110V DC |
100V DC/110V DC |
| Operating Temperature |
0°C to 60°C |
-10°C to 50°C |
–10°C to 70°C (PoE disabled)
–10°C to 60°C (PoE enabled) |
–10°C to 70°C (PoE disabled)
–10°C to 60°C (PoE enabled) |
–10°C to 70°C (PoE disabled)
–10°C to 65°C (PoE enabled) |
Dimensions
(H x W x D) |
44 mm x 200 mm x 160 mm |
44 mm x 200 mm x 160 mm |
44 mm x 280 mm x 200 mm |
44 mm x 280 mm x 200 mm |
44 mm x 280 mm x 200 mm |
