Dimensions (H x W x D)
|
44.4 mm x 442 mm x 421 mm
|
130.5 mm x 442 mm x 470 mm
|
|
Fixed Interfaces
|
8 x GE (RJ45) + 4 x GE (SFP)
|
USG6650/USG6660: 2 x 10 GE (SFP+) + 8 x GE (RJ45) + 8 x GE (SFP)
USG6670/USG6680: 4 x 10 GE (SFP+) + 16 x GE (RJ45) + 8 x GE (SFP)
|
|
USB2.0 Port
|
2 x USB Ports
|
2 x USB Ports
|
|
Expansion Slot
|
2 WSIC*
|
USG6650/USG6660: 6 WSIC
USG6670: 5 WSIC
USG6680: (AC) 5 WSIC; (DC) 3 WSIC
|
|
Expansion I/O
|
WSIC: 2 x 10 GE (SFP+) + 8 x GE (RJ45), 8 x GE (RJ45), 8 x GE (SFP), 4 x GE (RJ45) BYPASS
|
WSIC: 2 x 10 GE (SFP+) + 8 x GE (RJ45), 8 x GE (RJ45), 8 x GE (SFP), 4 x GE (RJ45) BYPASS
|
|
Local Storage
|
Optional: Supports a 300 GB or 600 GB hard disk (the hard disk is hot-swappable, but the hard disk card is not)
|
Optional: Supports 300 GB or 600 GB hard disks (RAID1 and hot-swappable)
|
|
AC Power Supply
|
100V to 240V, 50 Hz/60 Hz
|
100V to 240V, 50 Hz/60 Hz
|
|
DC Power Supply
|
NA
|
USG6650: NA
USG6660/USG6670/USG6680: –48V to –60V
|
|
Power Supplies
|
Single 170W AC power supply; optional dual AC power supplies
|
USG6650: Dual AC Power Supply
USG6660/USG6670/USG6680: Dual AC or dual DC power supplies
|
