Maximum Number of Controllers
|
16*
|
|
System Cache (dual-controller, expanded with the number of controllers)
|
256 GB to 2 TB
|
512 GB to 4 TB
|
512 GB to 4 TB
|
1 TB to 8 TB
|
|
Supported Storage Protocols
|
FC, iSCSI, InfiniBand, HTTP, and FTP
|
|
Type of Front-end Ports
|
8 Gbit/s, 16 Gbit/s FC, 10 GE iSCSI, and 56 Gbit/s InfiniBand
|
|
Type of Back-end Ports
|
SAS3.0
|
PCIe 3.0
|
SAS3.0
|
|
Maximum Number of SSDs
|
800
|
200
|
2,400
|
|
Supported Disk Types
|
600 GB/900 GB/1.8 TB/3.6 TB/7.68 TB* SAS SSD
|
1 TB/2 TB/4 TB NVMe SSD
|
600 GB/900 GB/1.8 TB/3.6 TB/7.68 TB* SAS SSD
|
|
Supported RAID Levels
|
RAID5, RAID6, and RAID-TP (tolerating simultaneous failure of 3 SSDs)
|
|
Maximum Number of Hosts
|
8,192
|
|
Maximum Number of LUNs
|
16,384
|
|
Value-added Features
|
SmartDedupe (intelligent inline de-duplication) SmartCompression (intelligent inline compression)
SmartThin (intelligent thin provisioning) SmartVirtualization (intelligent heterogeneous virtualization)
SmartMigration (intelligent LUN migration) HyperSnap (snapshot)
HyperReplication (remote replication) HyperMetro (gateway-free active-active solution)
|
|
Storage Management Software
|
DeviceManager (device management) UltraPath (multi-path management)
eService (remote maintenance management)
|
|
Operating System Compatibility
|
AIX, HP-UX, Solaris, Linux, and Windows
|
|
Supported Virtualization Environment Software
|
Huawei FusionSphere, VMware, XenServer, Hyper-V, and other virtualization platforms
VMware VAAI/VASA/SRM, Hyper-V, and other value-added features
Integration with vSphere and vCenter
|
