Specifications
|
OceanStor 18500 V3
|
OceanStor 18800 V3
|
|
Max. Number of Controllers
|
16
|
|
Max. Cache Size
|
16 TB
|
|
Supported Storage Protocols
|
Fibre Channel, FCoE, iSCSI, InfiniBand, NFS, CIFS, HTTP, and FTP
|
|
Port Types
|
1 Gbit/s Ethernet, 10 Gbit/s FCoE, 10 Gbit/s TOE, 8/16 Gbit/s Fibre Channel, 56 Gbit/s InfiniBand and SAS 3.0 (back-end, 4 x 12 Gbit/s per port)
|
|
Max. Number of Host Ports
|
384
|
|
Max. Number of Disks
|
6,400 (2.5 in.) or 3,072 (3.5 in.)
|
9,600 (2.5 in.) or 4,608 (3.5 in.)
|
| Max. Raw Capacity (All-SSD Configuration) |
23 PB |
34.6 PB |
| Max. IOPS (All-SSD Configuration) |
16,000,000 |
20,000,000 |
| Gateway Mode |
Supported |
|
Support for Computing Virtualization
|
Supported virtual machines: VMware, Citrix, Hyper-V, and FushionSphere
Value-added features related to virtual environments: support for VMware VAAI and integration of VSphere and VCenter
|
|
Data Protection Software
|
HyperSnap (snapshot), HyperClone (clone), HyperCopy (copy), HyperMirror (volume mirroring), HyperReplication (remote replication), HyperLock (WORM), HyperMetro (active-active storage arrays), and HyperVault (integrated backup)
|
|
Resource Efficiency Improvement
|
SmartQoS (intelligent QoS control), SmartPartition (intelligent cache partitioning), SmartCache (intelligent caching), SmartThin (intelligent thin provisioning), SmartMotion (intelligent data migration), SmartTier (intelligent storage tiering), SmartErase (intelligent data destruction), SmartMigration (intelligent LUN migration), SmartVirtualization (intelligent heterogeneous virtualization), SmartMulti-tenant (intelligent multi-tenant), SmartQuota (quota management), and SmartDedupe & SmartCompression (intelligent de-duplication and compression)
|
|
Storage Management Software
|
UltraPath (multipathing management), BCManager (disaster recovery management software), DeviceManager (software to manage a single device), eSight (centralized O&M and management), and Cloud Service (remote maintenance and management)
|
