| Form Factor |
U.2 |
U.2 |
HH-HL card |
U.2 |
HH-HL card |
| Bus Interface |
PCIe Gen 3.0 x 4 |
PCIe Gen 3.0 x 4 |
PCIe Gen 3.0 x 4 |
PCIe Gen 3.0 x 4 |
PCIe Gen 3.0 x 4 |
| NVMe Standard |
NVMe 1.2 |
NVMe 1.2 |
NVMe 1.2 |
NVMe 1.2 |
NVMe 1.2 |
| Usable Capacity |
800 GB; 1.2/2.0/3.2/4.0 TB |
800 GB; 1.2/1.6/2.0/3.2 TB |
800 GB; 1.2/1.6/3.2 TB |
6.4 TB |
6.4 TB |
Sequential Read/Write
Bandwidth @ 1 MB |
800 GB: 2.4/1.0 GB/s
1.2 TB: 2.9/1.7 GB/s
2.0 TB: 3.1/1.9 GB/s
3.2 TB: 2.9/1.8 GB/s
4.0 TB: 3.1/1.9 GB/s |
800 GB: 2.7/1.1 GB/s
1.2 TB: 3.1/1.8 GB/s
1.6 TB: 3.2/1.95 GB/s
2.0 TB: 2.75/1.55 GB/s
3.2 TB: 3.1/1.95 GB/s |
800 GB: 2.7/1.1 GB/s
1.2 TB: 3.1/1.8 GB/s
1.6 TB: 3.2/1.95 GB/s
3.2 TB: 3.1/1.95 GB/s |
6.4 TB: 3.0/1.8 GB/s |
6.4 TB: 3.0/1.8 GB/s |
Stable Random Read/Write
IOPS @ 4 KB |
800 GB: 600k/55k
1.2 TB: 710k/85k
2.0 TB: 800k/50k
3.2 TB: 715k/78k
4.0 TB: 760k/38k |
800 GB: 680k/100k
1.2 TB: 800k/160k
1.6 TB: 800k/175k
2.0 TB: 650k/110k
3.2 TB: 800k/170k |
800 GB: 680k/100k
1.2 TB: 760k/160k
1.6 TB: 800k/175k
3.2 TB: 800k/170k |
6.4 TB: 750k/40k |
6.4 TB: 750k/40k |
Max Random Write
IOPS @ 4 KB |
800 GB: 250k
1.2 TB: 405k
2.0 TB: 452k
3.2 TB: 428k
4.0 TB: 464k |
800 GB: 275k
1.2 TB: 428k
1.6 TB: 464k
2.0 TB: 380k
3.2 TB: 464k |
800 GB: 275k
1.2 TB: 428k
1.6 TB: 464k
3.2 TB: 464k |
6.4 TB: 200k |
6.4 TB: 200k |
Average Read/Write
Latency @ 4 KB |
88 µs/18 µs |
88 µs/18 µs |
88 µs/18 µs |
110 µs/20 µs |
110 µs/20 µs |
| Power Consumption |
7W to 21W |
7W to 22W |
7W to 22W |
7W to 25W |
7W to 25W |
| 5-year Endurance* |
1 DWPD
4.0 TB: 0.56 DWPD |
3 DWPD |
3 DWPD |
3 DWPD** |
3 DWPD** |
| Max. Data Written*** |
800 GB: 1.46 PBW
1.2 TB: 2.19 PBW
2.0 TB: 2.92 PBW
3.2 TB: 5.84 PBW
4.0 TB: 4.08 PBW |
800 GB: 4.38 PBW
1.2 TB: 6.57 PBW
1.6 TB: 8.76 PBW
2.0 TB: 10.95 PBW
3.2 TB: 17.52 PBW |
800 GB: 4.38 PBW
1.2 TB: 6.57 PBW
1.6 TB: 8.76 PBW
3.2 TB: 17.52 PBW |
6.4 TB: 35.04 PBW |
6.4 TB: 35.04 PBW
|
