huawei EA5800-X2
-
Model:
-
Detail:
-
Price:
Request For Quotation
- Free Technical Support
- Product Quality Protection
- On-time Shipment
- +86 755 8215 3862
- leo@uonel.com
- ywx39894
An EA5800-X2 service subrack provides 5 slots, including 2 slots for control boards, 1 slot for power board, and 2 slots for service boards. The fan tray of the EA5800-X2 service subrack has two fans and fan monitoring board H901FMSA, and functions heat dissipation, monitoring, and fan speed adjustment, which ensures that the device works at a stable temperature.
|
Specification |
Value |
|---|---|
|
Dimensions (H x W x D, excluding mounting ears) |
88.1 mm x 442.0 mm x 268.7 mm |
|
Dimensions (H x W x D, including mounting ears of IEC standard) |
88.1 mm x 482.6 mm x 268.7 mm |
|
Dimensions (H x W x D, including mounting ears of ETSI standard) |
88.1 mm x 535.0 mm x 268.7 mm |
|
Maximum fully-loaded weight (including mounting ears of IEC standard) |
9.4 kg |
Power supply parameters of the EA5800-X2
|
Specification |
Value |
|---|---|
|
Power supply mode |
DC (dual power for backup)/AC power + battery |
|
Rated voltage |
|
|
Working voltage range |
|
|
Maximum input current |
|
