Huawei CloudEngine CE12800 Series Data Center Switches
-
Model:
Huawei Data Center Switches -
Detail:
CloudEngine CE12800 series (CE12800 for short) switches are next-generation, high-performance core switches designed for data center and high-end campus networks. Using Huawei’s next-generation VRP8 software platform, CE12800 series switches provide stable, reliable, secure, high-performance L2/L3 switching capabilities to help build an elastic, virtualized, and high-quality network. -
Price:
$10.00
- Free Technical Support
- Product Quality Protection
- On-time Shipment
- +86 755 8215 3862
- leo@uonel.com
- ywx39894
Overview
CloudEngine CE12800 series (CE12800 for short) switches are next-generation, high-performance core switches designed for data center and high-end campus networks. Using Huawei’s next-generation VRP8 software platform, CE12800 series switches provide stable, reliable, secure, high-performance L2/L3 switching capabilities to help build an elastic, virtualized, and high-quality network.
Huawei CloudEngine CE12800 Series Data Center Switches
CloudEngine CE12800 series (CE12800 for short) switches are next-generation, high-performance core switches designed for data center and high-end campus networks. Using Huawei’s next-generation VRP8 software platform, CE12800 series switches provide stable, reliable, secure, high-performance L2/L3 switching capabilities to help build an elastic, virtualized, and high-quality network.
Item | CE12804S | CE12808S | CE12804 | CE12808 |
CE12812 |
CE12816 |
---|---|---|---|---|---|---|
Switching Capacity | 45 Tbit/s, 89 Tbit/s | 89 Tbit/s, 178 Tbit/s | 45 Tbit/s, 89 Tbit/s | 89 Tbit/s, 178 Tbit/s | 134 Tbit/s, 268 Tbit/s | 178 Tbit/s, 356 Tbit/s |
Forwarding Performance | 17,280 Mpps | 34,560 Mpps | 17,280 Mpps | 34,560 Mpps | 51,840 Mpps | 69,120 Mpps |
Service Slots | 4 | 8 | 4 | 8 | 12 | 16 |
Switching Fabric Module Slots | 2 | 4 | 6 | 6 | 6 | 6 |
Dimensions (W x D x H) | 442 x 620 x 352.8 (8U) | 442 x 620 x 708.4 (16U) | 442 x 813 x 486.15 (11U) | 442 x 813 x 752.85 (17U) | 442 x 813 x 975.1 (22U) | 442 x 905 x 1,597.4 (36U) |
Chassis Weight (empty) | < 60 kg | < 100 kg | < 110 kg | < 150 kg | < 190 kg | < 290 kg |
GE BASE-T Interface Card | |
CE-L48GT | 48-port 10/100/1,000 BASE-T Interface Card (RJ45) |
GE BASE-X Interface Card | |
CE-L48GS | 48-port 100/1,000 BASE-X Interface Card (SFP) |
10G BASE-X Interface Card | |
CE-L12XS | 12-port 10G BASE-X Interface Card (SFP/SFP+) |
CE-L24XS | 24-port 10G BASE-X Interface Card (SFP/SFP+) |
CE-L48XS | 48-port 10G BASE-X Interface Card (SFP/SFP+) |
40 GE Interface Card | |
CE-L06LQ | 6-port 40G Interface Card (QSFP+) |
CE-L12LQ | 12-port 40G Interface Card (QSFP+) |
CE-L24LQ | 24-port 40G Interface Card (QSFP+) |
CE-L36LQ | 36-port 40G Interface Card (QSFP+) |
100 GE Interface Card | |
CE-L04CF | 4-port 100 GE Interface Card (CFP) |
CE-L08CC | 8-port 100 GE Interface Card (CXP) |
CE-L12CF | 12-port 100 GE Interface Card (CFP2) |
CE-L12CQ | 12-Port 100G Interface Card (QSFP28) |
CE-L36CQ | 36-port 100 GE Interface Card (QSFP28) |
