ZTE ZXR10 T8000 Carrier-Class Router ZTE T8000 T1200 T600 400G Cluster Router
-
Model:
ZTE T8000 T1200 T600 400G Cluster Router -
Detail:
ZTE ZXR10 T8000 Carrier-Class Router -
Price:
$3000.00
- Free Technical Support
- Product Quality Protection
- On-time Shipment
- +86 755 8215 3862
- leo@uonel.com
- ywx39894
The ZXR10 T8000 core routers focus on the requirements of Internet core nodes, backbone network super nodes, large MAN core egress nodes and cloud computing data center egress gateways. They are designed to construct flat networks, implement unified bearing of all services and provide future proof sustainable network evolution solutions.
|
Specifications |
Models |
ZXR10 T8000 Cluster System/CFC |
ZXR10 T8000 Standalone System/LCC |
|
Capacity |
|
|
|
|
|
Cluster Mode |
Standalone, B2B, multi-chassis cluster |
|
|
Service Slots |
- |
18 |
|
|
Main Control Slots |
2 |
2 |
|
|
Switching Slots |
12 |
8 |
|
|
Physical |
|
|
|
|
|
Rack Unit |
41RU |
41RU |
|
Dimensions(H×W×D)mm |
1820×442×634 |
1820×442×634 |
|
|
Weights(kg) |
<240kg |
<470kg |
|
|
Services |
|
|
|
|
|
Interfaces and Links |
100GE, 40GE, 10GE, GE, 10G POS VLAN, QinQ Smartgroup, LACP |
|
|
Routing and Forwarding |
IPv4/IPv6 dual stack, RIP, OSPF, ISIS, BGP, MBGP, IGMP, MLD, PIM, MSDP ECMP, UCMP ACL, QoS/HQoS, QPPB, PBR |
||
|
MPLS, VPN & TE |
LDP, RSVP-TE, DS-TE MPLS L2/L3 VPN, GRE mVPN |
||
|
Availability |
VRRP, FRR, NSF/GR, NSR, ISC2U |
||
|
Equipment Security |
Control Plane Security, Security Authentication, uRPF, Mirroring, GTSM SSH, SFTP |
||
|
Maintenance |
LLDP, BFD, Eth OAM, OAM mapping, SQA, Netflow, NTP CLI, SNMP, XML, syslog |
||
|
Power Supply |
|
|
|
|
DC |
Working Voltage(DC) |
-72V~-38V |
-72V~-38V |
|
Power Redundancy(DC) |
11+1 |
11+1 |
|
|
AC |
Working Voltage(AC) |
AC: 90V~286V HVDC: 192V~400V |
AC: 90V~286V HVDC: 192V~400V |
|
Power Redundancy(AC) |
8+8 |
8+8 |
|
|
Environments |
|
|
|
|
|
Working Temperature |
-5°C~+45°C |
-5°C~+45°C |
|
Working Humidity |
5%~90% |
5%~90% |
|
