ZTE MDU, ZXA10 F820,F821,F822, GPON ONU used in an FTTB/FTTO scenario

ZTE F822 F822-8FE F822-16FE F822-24FE EPON GPON ONU MDU

ZXA10 F822 is a GPON Optical Network Unit used in an FTTB/FTTO scenario. ZXA10 F822 supports VoIP, data and TDM services access. It builds a multi-tenant network center with computer technology and broadband optical network access technology, which connects various business appliances and equipments into the network to share Internet/voice connections so as to provide users with rich, diversified, personalized, convenient, comfortable, safe and effective services.

ZXA10 F822 provides 1/2 GPON interface to connect OLT with an ODN. It offers a new choice for operators to deliver FTTB/FTTO access.

Interface Function

Optical port (line terminal):
1/2 * GPON interface (SC/APC)
User network interface:
24/16/8 * 10/100Base_T interfaces
24/16/8 * VoIP interfaces
1* 10/100/1000Base_T interfaces

Transmission Rate

Line terminal: 2.488Gbps downstream and
1.244Gbps upstream
User side interface: 10/100Mbps autonegotiation

Transmission Distance

Link distance: 0 ~ 20km max

Transmission Wavelength

Receiving: 1,490 nm
Transmitting: 1,310 nm

Receiving Sensitivity

Better than -29dBm

Transmitting Optical Power

1~5dBm

Overload Optical Power

-5dBm

Physical Performance

Power consumption: 35.2W(24FE+24POTS)/
28.5W(16FE+16POTS) / 22W(8FE+8POTS)
Dimensions: 43.6 mm(H) * 482.6mm (W) *240 mm (D)
Working temperature: -30°C ~ 60°C
Working humidity: 5% ~ 95%
Weight: <4.5kg
Power supply: -48V DC or/and 110V/220 V AC
Mounting mode: Rack/Cabinet/Wall mounted

Service Function

Service: VoIP, Internet, IPTV
SIP/H.248/MGCP
G.711 , G.723.1, G.729a/b
Auto registration at power-on
802.1Q, 802.1P, 802.1ad and QoS policy
MAC addresses: 16K
STP, RSTP
IGMP snooping/proxy and controllable multicast
Support SP, WRR and SP+WRR
Loop back test for user ports
AES-128 Decryption
DBA and FEC
Priority queues and scheduling
4k VLAN, 4MVLAN
Up to 40T-CONTs and 256 GEM Ports
