Huawei ES3720S V3 SAS SSD

  • Model:

    Huawei ES3720S V3 SAS SSD
  • Detail:

    Huawei ES3000 V3 Series SAS SSD products
  • Price:

    $2000.00

  • Condition:

    Brand New Sealed
  • Availability:

    IN STOCK

  • Quantity:

  • Free Technical Support
  • Product Quality Protection
  • On-time Shipment
Overview
Huawei ES3000 V3 Series SAS SSD products



Specifications

Model

ES3520S V3

ES3620S V3

ES3720S V3

Form Factor

2.5-inch disk

2.5-inch disk

2.5-inch disk

Bus Interface

SAS 3.0 12 Gbit/s

SAS 3.0 12 Gbit/s

SAS 3.0 12 Gbit/s

Usable Capacity

960 GB, 1.92 TB/3.84 TB

800 GB, 1.6 TB/3.2 TB

400 GB/800 GB, 1.6 TB

Sequential Read/Write Bandwidth @ 128 KB



960 GB: 1,050/700 MB/s
1.92 TB: 1,050/900 MB/s
3.84 TB: 1,050/900 MB/s



800 GB: 1,050/700 MB/s
1.6 TB: 1,050/900 MB/s
3.2 TB: 1,050/900 MB/s

400 GB: 1,000/700 MB/s

800 GB: 1,000/900 MB/s

1.6 TB: 1,000/900 MB/s

Stable Random Read/Write IOPS @ 4 KB



960 GB: 200k/30k
1.92 TB: 200k/35k
3.84 TB: 200k/35k



800 GB: 200k/60k
1.6 TB: 200k/75k
3.2 TB: 200k/80k

400 GB: 200k/90k

800 GB: 200k/95k

1.6 TB: 200k/95k

Average Read/Write Latency @ 4 KB

135 µs/40 µs

135 µs/40 µs

140 µs/40 µs

Power Consumption

4.5W to 12W

4.5W to 12W

4.5W to 12W

5-year Endurance*

1 DWPD

3 DWPD

15 DWPD

Maximum Data Written**

960 GB: 1.75 PBW

1.92 TB: 3.5 PBW

3.84 TB: 7 PBW

800 GB: 4.38 PBW

1.6 TB: 8.76 PBW

3.2 TB: 17.52 PBW

400 GB: 7.3 PBW

800 GB: 14.6 PBW

1.6 TB: 29.2 PBW

* 5-year Endurance: Disk Writes per Day (DWPD) over 5 years

** Maximum Data Written: Petabyte Writes (PBW); 100% random write tested with 4 KB IO size and 4 KB alignment

Notes: Specifications are subject to change without notice. Performance results are based on internal testing and use. Results and performance may vary according to configurations and systems, including drive capacity, system architecture, and applications. The above shows the performance of a single SAS port.
