Dimensions (H x W x D)
|
1420 mm (32U) x 442 mm x 650 mm (55.91 in. x 17.40 in. x 25.59 in.) (chassis main body dimensions)
1420 mm (32U) x 442 mm x 770 mm (55.91 in. x 17.40 in. x 30.31 in.) (chassis dimensions including the chassis's front and rear assembly and cable racks)
|
|
Installation position
|
N68E cabinet or a standard 19-inch cabinet or a 23-inch rack that complies with the North American standard
|
|
Weight
|
Empty chassis
|
69.6 kg (153.47 lb)
|
|
Full configuration (maximal)
|
279 kg (615.20 lb)
|
|
Integrated chassis
|
94.4 kg (208.15 1b)
|
|
Typical power consumption
|
6210 W
|
|
Heat dissipation
|
20147.9 BTU/hour
|
|
DC input voltage
|
Rated voltage
|
-48 V DC / -60 V DC
|
|
Maximum voltage range
|
-38.4 V DC to -72 V DC
|
|
AC input voltage
|
Rated voltage
|
200 V AC to 240 V AC(220V)
|
|
Maximum voltage range
|
180 V AC to 264 V AC
|
|
System reliability
|
MTBF (year)
|
21.66
|
|
MTTR (hour)
|
0.5
|
|
Ambient temperature
|
Long-term
|
0°C to 45°C (32°F to 113°F)
|
|
Short-term
|
-5°C to 55°C (23°F to 131°F)
|
|
Remarks
|
Limit of the temperature change rate: 30°C (86 °F)/hour
|
|
Storage temperature
|
-40°C to 70°C (-40°F to 158°F)
|
|
Relative humidity
|
Long-term
|
5% RH to 85% RH, no coagulation
|
|
Short-term
|
5% RH to 95% RH, no coagulation
|
|
Storage humidity
|
5% RH to 95% RH, no coagulation
|
|
Long-term altitude
|
≤ 4000 m (13123.2 ft). If the altitude is between 1800 meters (5905.44 ft) and 4000 meters, the maximum operating temperature of the device must decrease by 1°C for every 220 meters (721.776 ft) increase in altitude.
|
|
Storage altitude
|
Lower than 5000 m (16404 ft)
|
